cavalon
AutoGyro’s premier side-by-side offering is a real masterpiece in design, execution, and production bringing the social aspect of flying normally reserved for airplanes to the gyro world. With nearly 500 Cavalons produced, this cross country touring machine is enjoyed by adventurers and flight schools alike worldwide. Whether equipped with basic instrumentation or the latest in Garmin touchscreen avionics all Cavalons benefit from AutoGyro’s latest rotorhead III and Rotax’s 915iS for the smoothest most powerful gyro experience and shortfield capability with 320 rotor rpm pre-rotation capability.
The new Type Certificated Cavalon, starting at $162,000*, turnkey and ready to explore in the USA.
* pricing is dependent on current Euro to US Dollar Exchange Rates & subject to change
For a current build quote email fly@autogyronewyork.com
side by side adventures
As a side-by-side touring model, Cavalon sits at the top of the product range offering a huge variety of features. With nearly 26 gallons of usable fuel, Cavalon handles great distances easily and flight endurance time nearing 6 hours.
Multiple adjustments to both pilot and passenger seating positions, rudder pedals, and electronically controlled lumbar support allow absolute comfort to easily avoid fatigue when spending the day aloft. A wide cabin ensures personal space is maintained even though seated side by side.
For cold weather operations dual level heated seats and cabin heating warms the cockpit without any possibility of pilot incapacitation from carbon monoxide for it is coolant and not exhaust based.
The expansive instrument panel has space to incorporate a wide range of avionics as well as surveillance equipment for industry and law enforcement.
Side-by-Side Cockpit View from a flight over Manhattan Beach, Los Angeles
glass cockpit
The Cavalon can now be equipped with the latest glass cockpit option: Garmin G3X. Designed specifically for light sport aircraft, this scalable system lets you grow as your needs and budget allow. Read more about the Garmin G3X here.
Standard Instruments & Avionics
Analog Flight Instruments, Funkwerk ATR833 VHF Comm Radio, TRIG TT22 Transponder w/ ADS-B Out, Card Compass
Optional Instruments & Avionics
Garmin Flight Deck Suites (Single G3X 10.6” Touch Display, Dual G3X 7” Touch Displays, G3X 10.6” & G3X 7” Touch Displays) ELT Kannad AF 406 Emergency Location Transmitter
GENERAL SPECIFICATIONS
Seats - Two/Side by Side
Empty Weight - 710 -760lbs
Max Takeoff Weight - 1235 lbs
Maximum Pilot Weight - 242 lbs
Useful Load - 475 -525 lbs
PERFORMANCE
Max Speed - 120 mph
Cruise Speed - 75-110 mph
Minimum Speed - 25 mph
Range - 380 sm @ 100 mph (+30 minute reserve) - 430 sm @ 87 mph (+30 minute reserve) - 470 sm @ 78 mph (+30 minute reserve)
Maximum Climb Rate (MGTW) - 1000 ft/min
Service Ceiling - 12,000 feet
Take off Roll (MGTW no wind) - 300 feet
Landing Roll (no wind) - 60 feet
Maximum Endurance - 6 hours + 30 minute reserve
FUEL
Fuel Consumption - 3.5 – 7 gallons/ hour
Fuel Type - Premium Automotive
Fuel Tank Capacity - 25.9 gallons
ENGINE
Engine Option - Rotax 915iS
Horsepower - 141
Fire Warning System - Yes
AVIONICS
Standard - Analog Flight Instruments, Funkwerk ATR833 VHF Comm Radio, TRIG TT22 Transponder w/ ADS-B Out, Card Compass
Optional - Garmin Flight Deck Suites (Single G3X 10.6” Touch Display, Dual G3X 7” Touch Displays, G3X 10.6” & G3X 7” Touch Displays) ELT Kannad AF 406 Emergency Location Transmitter
PRE-ROTATION & ROTORBLADE
Pre-rotation Range - 200-320 RPM
Pre-rotation Engagement - Electronically Initiated, Pneumatically Actuated
Pre-rotation Protection - Yes
Pre-rotation Interruptible - No
Pre-rotation From Either Seat - Yes
Rotor Type - NACA 8H12 extruded aluminum RSII TOPP 8.4m or 8.6m
WARRANTY
Warranty of the Engine - As per Rotax (18 months / 200 hours)
Warranty of Airframe - 200 hours / 12 months
DIMENSIONS
Length - 15 feet 7 inches
Height - 9 feet 1 inches
Width - 5 feet 10 inches
Rotor Diameter - 27 feet 7 inches / 28 feet 3 inches
Airframe Construction Material - Composite / 4130 Chromoly Steel
Hull - Composite Monocoque
Tail - Carbon Fiber
Propeller Material - Composite
Power Outlet Voltage - 12 volt
Nav/Strobe/Recognition Lights - Yes
High Intensity Landing Light - Optional
gallery
support
Flight Manuals
Flight manuals are available upon request.
Financing
Interested in purchasing an aircraft but need some assistance with the payment? Check out LightStream. They offer excellent rates for an unsecured loan as well as an online approval process that is fast, easy and virtually paperless.
Insurance
Are these aircraft insurable? Yes, they are. Insurance rates will vary depending on the pilot's experience, model etc. We recommend that you contact our insurance broker:
Aviation Insurance Resources
Victoria Neuville
P.O. Box 32
Frederick, MD 21705
T. (301) 682-6200
F. (301) 682-9793
vneuville@air-pros.com
Maintenance
All maintenance is done by AutoGyro New York’s exclusive training and service center Gyro Revolution. Looking for the 25/100 Hour Inspection Protocol Checklists, Ground Test Run Info or Maintenance Manuals for your AutoGyro aircraft?
Please contact AutoGyro New York via phone or email to be sure you have a current copy of this information.
